References
Programming Guide Job Planning (PGA) Chapter: Motion-synchronous actions
Status of synchronized actions
You can see the status of the synchronized actions in the "Status" column.
● Waiting
● Active
● Blocked
Non-modal synchronized actions can only be identified by their status display. They are only
displayed during execution.
Synchronization types
Synchronization types Meaning
ID=n Modal synchronized actions in the automatic mode up to the end of pro‐
gram, local to program; n = 1... 254
IDS=n Static synchronized actions, modally effective in every operating type, also
beyond the end of program; n = 1... 254
Without ID/IDS Non-modal synchronized actions in the automatic mode
Note
Numbers from the number range 1 to 254 can only be assigned once, irrespective of the
identification number.
Display of synchronized actions
Using softkeys, you have the option of restricting the display to activated synchronized actions.
Procedure
1. Select the "Machine" operating area.
2.
Press the <AUTO>, <MDA> or <JOG> key.
3. Press the menu forward key and the "Synchron." softkey.
The "Synchronized Actions" window appears.
You obtain a display of all activated synchronized actions.
Machining the workpiece
6.14 Displaying superimpositions
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 255
