Procedure
1. Select the "Machine" operating area.
3. Press the "Times, Counter" softkey.
The "Times, Counter" window opens.
4. Select "Yes" under "Count workpieces" if you want to count completed
workpieces.
5. Enter the number of workpieces needed in the "Desired workpieces" field.
The number of workpieces already finished is displayed in "Actual work‐
pieces". You can correct this value when required.
After the defined number of workpieces is reached, the current workpie‐
ces display is automatically reset to zero.
See also
Specifying the number of workpieces (Page 341)
Machining the workpiece
6.16 Displaying the program runtime and counting workpieces
Milling
266 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
