<CTRL> + <E>
Calls the "Ctrl Energy" function.
<CTRL> + <F>
Opens the search dialog in the machine data and setting data lists,
when loading and saving in the MDI editor as well as in the program
manager and in the system data.
<CTRL> + <G>
● Switches in the program editor for ShopMill or ShopTurn
programs between the work plan and the graphic view.
● Switches in the parameter screen between the help display and
the graphic view.
<CTRL> + <I>
Calculates the program runtime up to or from the selected set/block
and displays a graphic representation of the times.
<CTRL> + <L>
Scrolls the actual user interface through all installed languages one
after the other.
<CTRL> + <SHIFT> + <L>
Scrolls the actual user interface through all installed languages in
the inverse sequence.
<CTRL> + <M>
Selects the maximum feedrate of 120% during the simulation.
<CTRL> + <P>
Generates a screenshot from the actual user interface and saves it
as file.
<CTRL> + <S>
Switches the single block in or out in the simulation.
<CTRL> + <V>
● Pastes text from the clipboard at the actual cursor position.
● Pastes text from the clipboard at the position of a selected text.
<CTRL> + <X>
Cuts out the selected text. The text is located in the clipboard.
<CTRL> + <Y>
Reactivates changes that were undone (only in the program edi‐
tor).
<CTRL> + <Z>
Undoes the last action (only in the program editor).
Introduction
2.2 Operator panel fronts
Milling
32 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
