Parameters Description Unit
∅A Outer diameter ∅ mm
ØI Inner diameter Ø (abs) or wall thickness (inc) mm
● Centered cuboid
W Width of blank mm
L Length of blank mm
● Cuboid
X0 1st corner point X mm
Y0 1st corner point Y mm
X1 2nd corner point X (abs) or 2nd corner point X referred to X0 (inc) mm
Y1 2nd corner point X (abs) or 2nd corner point X referred to X0 (inc) mm
ZA Initial dimension mm
ZI Final dimension (abs) or final dimension in relation to ZA (inc) mm
● Polygon
N Number of edges
SW
L
Width across flats
Edge length
mm
● Without
No blank use
HA Initial dimension mm
HI Final dimension (abs) or final dimension in relation to HA (inc) mm
PL Machining plane
● G17 (XY)
● G18 (ZX)
● G19 (YZ)
RP Retraction plane (abs) mm
SC Safety clearance (inc)
Acts in relation to the reference point. The direction in which the safety clearance is effec‐
tive is automatically determined by the cycle.
mm
Machining
direction
Milling direction
● Down-cut
● Up-cut
Retraction position
pattern
Lift mode before new infeed
● To RP
● Optimized
mm
