Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Deep-hole drilling" and "Deep-hole drilling 2" softkeys.
The "Deep-hole Drilling 2" input window opens.
Parameters in the "Input complete" mode
G code program parameters ShopMill program parameters
Input
● Complete
PL Machining plane
RP Retraction plane mm T Tool name
SC Safety clearance mm D Cutting edge number
F Feedrate distance/min
distance/rev
F Linear feedrate
Revolutional feedrate
mm/min
mm/rev
S / V
Direction of spindle rotation
during drilling
S / V Spindle speed /
Constant cutting rate
rpm
m/min
Spindle speed /
Constant cutting rate
rpm
distance/min
Parameter Description Unit
Machining
position (only
for G code)
● Single position
Drill hole at programmed position
● Position pattern with MCALL
Z0 (only G
code)
Reference point Z mm
Drilling depth
● Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
● Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value
programmed for Z1.
Z1 Final drilling depth (abs) or final drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
Coolant on -
(only G code)
M function to switch on the coolant.
Programming technological functions (cycles)
10.1 Drilling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 387
