Parameter Description Unit
Through drilling
● Yes
Through drilling with feedrate FD
● No
Drilling with constant feedrate
ZD - (only for
through drilling
"yes")
Depth for feedrate reduction (abs) or depth for feedrate reduction in relation to Z1
(inc)
mm
FD - (only for
through drilling
"yes")
Feedrate for through drilling referred to drilling feedrate F. %
Feedrate for through drilling (ShopMill) mm/min or mm/rev.
Feedrate for through drilling (G code). distance/min or dis‐
tance/rev
DT - (only for
through drilling
"no")
● Dwell time at final depth in seconds
● Dwell time at final depth in revolutions
s
U
Retraction
● Retraction to pilot hole depth
● Retraction to retraction plane
FR Retraction (G code)
● with rapid traverse
● Feedrate for retraction
distance/min
Retraction (ShopMill)
● with rapid traverse
● Feedrate for retraction
mm/min
SR / VR Retraction with sta‐
tionary spindle
Direction of spindle
rotation during re‐
traction
Spindle speed for retraction to the drilling speed %
Spindle speed for retraction rpm
Constant cutting rate for retraction (G code) distance/min
Constant cutting rate for retraction (ShopMill) m/min
Coolant off -
(only G code)
M9 - M function to switch off the coolant
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
Programming technological functions (cycles)
10.1 Drilling
Milling
390 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
