Parameter Description Unit
FS First cut feedrate as a percentage of the drilling feedrate %
First cut feedrate (G code) distance/min or
distance/rev
First cut feedrate (ShopMill) mm/min or mm/
rev.
ZS2 - (only "Yes"
for soft first cut)
First cut depth (abs) or depth of each cut for the feedrate increase (ink) mm
Through drilling
● Yes
Through drilling with feedrate FD
● No
ZD - (only for
through drilling
"yes")
Depth for feedrate reduction (abs) or depth for feedrate reduction in relation to Z1
(inc)
mm
FD - (only for
through drilling
"yes")
Feedrate for through drilling as a percentage of the drilling feedrate %
Feedrate for through drilling (G code). distance/min or
distance/rev
Feedrate for through drilling (ShopMill) mm/min or mm/
rev.
Coolant off -
(only G code)
M9
M function to switch off the coolant
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter Description Value Can be set in SD
PL (only for G code) Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Drilling depth Drilling depth referred to the shaft or tip Tip
Entrance to the hole Technology at the entrance to the hole With pilot hole
ZA Predrilling depth (inc) 1mm
FA Predrilling feed 50 %
Drilling
interruption
● One cut
● Chip breaking
● Swarf removal
● Chip breaking and swarf removal
D 1. Drilling depth referred to Z0 (inc.) 10 mm
FD1 Percentage for the feedrate for the first infeed
Programming technological functions (cycles)
10.1 Drilling
Milling
392 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
