Parameter Description Unit
X0
Y0
α0
R
N
Positioning
Axes XY (at right angles)
X coordinate of the reference point X (abs)
Y coordinate of the reference point Y (abs)
Starting angle for first position.
Positive angle: Full circle is rotated counter-clockwise.
Negative angle: Full circle is rotated in clockwise direction.
Radius
Number of positions
Positioning motion between the positions
● Straight line
Next position is approached linearly in rapid traverse.
● Circle
Next position is approached along a circular path at the feedrate defined in the
machine data.
mm
mm
Degrees
mm
X0
A0
N
Axes: XA
X coordinate of the reference point (abs)
Start angle of the A axis (abs)
Number of positions
mm
Degrees
Parameters - "Pitch circle" position pattern
Parameter Description Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Axes
Selection of the participating axes
● XY (1st and 2nd axis of the plane)
● XA (1st rotary axis and assigned linear axis)
Note:
Rotary axes are only displayed in the selection field if they have been released for use
in the position pattern.
Please observe the information provided by your machine manufacturer.
Z0 Z coordinate of the reference point mm
Programming technological functions (cycles)
10.1 Drilling
Milling
416 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
