Parameter Description Unit
Solid machining
(for roughing only)
● Complete machining
The rectangular pocket is milled from the solid material.
● Post machining
A rectangular pocket or hole has already been machined in the workpiece. This needs
to be enlarged in one or several axes. You must program parameters AZ, W1 and
L1 for this purpose.
AZ Depth of premachining – (for remachining only) mm
W1 Width of premachining – (for remachining only) mm
L1 Length of premachining – (for remachining only) mm
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) – (for chamfer only) mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
Milling direction T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
X0
Y0
Z0
The positions refer to the reference point:
Reference point X – (single position only)
Reference point Y – (single position only)
Reference point Z – (only single position and G Code position pattern)
mm
mm
mm
W Pocket width mm
L Pocket length mm
R Corner radius mm
Z1 Depth referred to Z0 (inc) or pocket depth (abs) - (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
Programming technological functions (cycles)
10.2 Milling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 427
