Parameter Description Unit
FZ
(only for ShopMill)
Depth infeed rate – (only for insertion and vertical insertion) mm/min
mm/tooth
EP Maximum pitch of helix - (for helical insertion only)
The helix pitch may be lower due to the geometrical situation.
mm/rev
ER Radius of helix - (only for helical insertion)
The radius must not be larger than the milling cutter radius, otherwise material
will remain. Also make sure the circular pocket is not violated
mm
Solid machining
● Complete machining
The circular pocket must be milled from a solid workpiece (e.g. casting).
● Post machining
A small pocket or hole has already been machined in the workpiece. This
needs to be enlarged. Parameters AZ, and ∅1 must be programmed.
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
AZ Depth of premachining - (for remachining only) mm
∅1 Diameter of premachining - (for remachining only) mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
Milling direction T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Programming technological functions (cycles)
10.2 Milling
Milling
434 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
