Note
Predrilling position
The position at which insertion is performed if "predrilled" is selected, is the same position that
you select when specifying the reference point with "left inside". In the case of a slot without
an angle of rotation, the predrilled position is the center point of the left rounding radius of the
slot. When the cycle is called on a position circle, the predrilled position is always the center
point of the rounding radius that is closer to the center point.
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
Milling direction T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
X0
Y0
Z0
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
W Slot width mm
L Slot length mm
α0 Angle of rotation Degrees
Z1 Slot depth (abs) or depth relative to Z0 (inc) – (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
DXY
(only for ShopMill)
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed – (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
Programming technological functions (cycles)
10.2 Milling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 453
