Parameter Description Unit
Z1
● Intermediate point 1 Z (abs) or
● Intermediate point 1 in relation to Z0 (inc)
mm
P1 Thread pitch 2 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X2 or X2α
● Intermediate point 2 X ∅ (abs) or
● Intermediate point 2 in relation to X1 (inc) or
● Thread taper 2
Incremental dimensions: The sign is also evaluated.
mm
Degrees
Z2
● Intermediate point 2 Z (abs) or
● Intermediate point 2 in relation to Z1 (inc)
mm
P2 Thread pitch 3 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X3
● End point X ∅ (abs) or
● End point 3 in relation to X2 (inc) or
● Thread taper 3
mm
Degrees
Z3
● End point Z ∅ (abs) or
● End point with reference to Z2 (inc)
mm
LW Thread run-in mm
LR Thread run-out mm
H1 Thread depth mm
DP or αP Infeed slope (flank) or infeed slope (angle) mm or de‐
grees
● Infeed along a flank
● Infeed with alternating flanks
D1 or ND First infeed depth or number of roughing cuts - (only for ∇ and ∇ + ∇∇∇) mm
rev Finishing allowance in X and Z - (only for ∇ and ∇ + ∇∇∇) mm
NN Number of noncuts - (only for ∇∇∇ and ∇ + ∇∇∇)
VR Return distance mm
Multiple threads No
α0 Starting angle offset Degrees
Yes
N Number of thread turns
DA Thread changeover depth (inc) mm
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
566 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
