Parameters in the "Input complete" mode
G code program parameters ShopMill program parameters
Input
● Complete
PRG Name of the program to be generated T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane – (only for
machining direction, longitu‐
dinal, inner)
mm F Feedrate mm/min
mm/rev
SC Safety clearance mm S / V Spindle speed or
constant cutting rate
rpm
m/min
F Feedrate *
Residual
material
With subsequent residual material removal.
● Yes
● No
CONR Name to save the updated unmachined-part
contour for residual material removal - (only
"Yes" for residual material removal).
Parameter Description Unit
TC Name of the swivel data set
Note: The selection box only appears if more than one swivel data set has been set
up.
Retraction
(for ShopMill pro‐
gram)
● No
The axis is not retracted before swiveling.
● Z
Retraction in the direction of machine axis Z.
● Z,X,Y
Move machining axes to retraction position before swiveling.
● Tool direction, max.
Maximum retraction (up to the software end position) in the tool direction.
● Tool direction, inc.
Incremental retraction (specified retraction distance, up to the software end
position) in the tool direction.
When retracting in the tool direction, in the swiveled machine state, several axes can
move (traverse).
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 591
