Parameter Description Unit
C1
(for ShopMill pro‐
gram)
The required angle can be freely entered. Degrees
αC
(for ShopMill pro‐
gram)
Rotational position for a pole position. Degrees
Hirth joint
● Round to the next Hirth joint
● Round up to Hirth joint
● Round down to Hirth joint
Note:
For machines with a Hirth joint
Tool
Tool tip when swiveling
● Tracking
The position of the tool tip is maintained during swiveling.
● No tracking
The position of the tool tip is not maintained during swiveling.
Preferred direc‐
tion (for ShopMill
program)
Preferred direction of the swivel axis for several possible alignments of the machine.
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
Machining
direction
● Face
● Longitudinal
● Parallel to the contour
● From inside to outside
● From outside to inside
● From end face to rear side
● From rear side to end face
The machining direction depends on the stock removal direction and choice of tool.
Position
● Front
● Rear
● Inside
● Outside
D Maximum depth infeed - (only for ∇) mm
XDA First grooving limit tool (abs) – (only for face machining direction). mm
XDB Second grooving limit tool (abs) – (only for face machining direction). mm
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
602 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
