G code program parameters ShopMill program parameters
PRG Name of the program to be gener‐
ated
T Tool name
PL Machining
plane
D Cutting edge
number
RP Retraction
plane – (only for
machining di‐
rection, longitu‐
dinal, inner)
mm F Feedrate mm/min
mm/rev
SC Safety clear‐
ance
mm S / V Spindle speed
or
constant cut‐
ting rate
rpm
m/min
F Feedrate *
CON Name of the updated unma‐
chined-part contour for residual
material machining (without the
attached character "_C" and dou‐
ble-digit number)
Residual mate‐
rial
With subsequent residual materi‐
al removal.
● Yes
● No
CONR Name to save the updated unma‐
chined-part contour for residual
material removal - (only "Yes" for
residual material removal).
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
614 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
