Parameter Description Unit
XDB Second grooving limit tool ∅ (abs) – (end face or rear face only) mm
Allowance Allowance for prefinishing
Yes
U1 contour allowance
No
DI For zero: Continuous cut - (only for ∇) mm
XD - (only for blank description, cylinder and allowance)
For blank description, cylinder
Allowance or cylinder dimension ∅ (abs)
Allowance or cylinder dimension (inc)
For blank description, allowance
Allowance on the contour ∅ (abs)
Allowance on the contour (inc)
mm
ZD - (only for blank description, cylinder and allowance)
For blank description, cylinder
Allowance or cylinder dimension (abs or inc)
For blank description, allowance
Allowance on the contour (abs or inc)
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
Positive value: Compensation allowance is retained
Negative value: Compensation allowance is removed in addition to finishing allowance
mm
Set machining
area limits
Set machining area limits
Yes
No
XA
XB
ZA
ZB
With limited machining area only, yes:
1st limit XA ∅
2nd limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1st limit ZA
2nd limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves (inc) mm
* Unit of feedrate as programmed before the cycle call
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
630 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
