G code program parameters ShopMill program parameters
PL Machining plane T Tool name
D Cutting edge number
F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting
rate
rpm
m/min
Parameter Description Unit
TC Name of the swivel data record
Retraction No No retraction before swiveling
Incremental retraction in tool direction
The retraction path is entered into parameter ZR.
Maximum retraction in tool direction
Retraction in the direction of machine axis Z
Retract towards the machine axis Z and then in the direction
X, Y
ZR Retraction path - (only for incremental retraction in the tool direction)
Swivel plane
● New: New swivel plane
● Additive: Additive swivel plane
X0 Reference point for rotation X
Y0 Reference point for rotation Y
Z0 Reference point for rotation Z
Swivel mode
● Axis by axis: Rotate coordinate system axis-by-axis
● Solid angle: Swivel via solid angle
● Proj. angle: Swiveling via projection angle
● Direct: Directly position rotary axes
Axis sequence Sequence of the axes which are rotated around: - (only for axis-by-axis swivel mode)
XYZ or XZY or YXZ or YZX or ZXY or ZYX
X Rotation around X - (only for axis sequence) Degrees
Y Rotation around Y Degrees
Z Rotation around Z Degrees
Projection position Position of the projection in space - (only for swivel mode, projection angle)
Xα, Yα, Zβ or Yα, Zα, Zβ or Zα, Xα, Zβ
Xα Projection angle - (only for projection position) Degrees
Yα Projection angle Degrees
Zβ Angle of rotation in the
plane
Degrees
Programming technological functions (cycles)
10.6 Further cycles and functions
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 639
