Entry Description
Partition Partition number on the USB storage medium,
e.g. 1 or all.
If a USB hub is being used, then specify the
USB port of the hub.
USB path Path to the USB hub.
Note:
This value is not currently evaluated.
Specifications for local drives
Entry Description
Symbolic Symbolic drive name.
Assignment of the names under Details
Additional parameters under Details
Use drive as: LOCAL_DRIVE The activation of the checkbox assigns the
symbolic name to the drive.
If an assignment exists already for the drive,
no change can be made.
All checkboxes are active as preassignment.
CF_CARD
SYS_DRIVE
Specifications for network drives
Entry Description
Computer name Logical name of the server or the IP address.
Release name Only for network drives in
Windows systems.
Name, under which the network drive was re‐
leased
Path Start directory.
The path is specified relative to the released
directory.
User name
Password
Enter the user name and the corresponding
password for which the directory is enabled on
the server.
The password is displayed in encoded form
as string of "*" characters and is stored in the
"logdrive.ini" file.
Symbolic Symbolic drive name.
Maximum 12 characters can be entered (let‐
ters, digits, underscore).
The names NC, GDIR and FTP are reserved.
They are also used to label the softkey if a
softkey text is not specified.
Managing programs
14.12 Set up drives
Milling
778 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
