Siemens SIPART DR22 User Manual

3 Operation
3.3 Configuring Mode (Parameterization and Configuring Mode)
3.3.2 Parameterization Mode AdAP (Adaptation)
Manual
142
SIP ART DR24 6DR2410
C79000-G7476-C153-03
Pre adaptation:
xx.o value or PAST
xx.n Strt:
after adaptation
xx.o value or PAST
xx.n value or no
Adjustment of parameter name
Pre adaptation: no function
Post adaptation: adjustment of parameter
value
Enter key Pre adaptation ↗:startof
adaptation
Post adaptation: no function
Pre adaptation:
xx.o Pi or Pid
xx.n AdAP
post adaptation:
xx.o Pi or Pid
xx.n Pi.x and
Pid.x
Exit key ↗: return to parameterization mode
after AdAP
Exit LED: flashes
Parameter name
tU,dPv,dY,vv.o,
vv.n ... AH.o, AH.n
flashing
x=lineorder1to8
xx = parameter name
All unnamed control and display elements have the
connected function
dd1
dd2
dA2/
L14
dA1
tA1
tA2
tA3
tA4
tA5
tA6
tA7
L13
L1
L2
L4
L3
L5
L6
L7
L9
L8
L10
L11
dd3 L12
Figure 3-6 Control and display elements before and after adaptation in the parameterization
mode AdAP
dd1
dd2
dA2/
L14
dA1
tA1
tA2
tA3
tA4
tA5
tA6tA7
L13
L1
L2
L4
L3
L5
L6
L7
L9
L8
L10
L11
dd3 L12
During ad aptation:
connected function
after ab ortion:
error Message
Enter key During adaptation ↗: no function
After abortion: error acknowledgement
During ad aptation:
connected function
after ab ortion:
error Message
Exit key ↗: manually aborted adaptation, return to
parameterization mode after AdAP
Exit LED: flashes
All unnamed control and display elements have the
connected function
Figure 3-7 Control and display elements during and at abortion of adaptation in the
parameterization mode AdAP
