Prerequisites
1. Set the "1.YFCT" parameter of the positioner to "ncSLL".
2. Launch initialization as usual with "INITA".
7 Technical specifications
Additional modules Without explosion protection With Ex protection
Ex "ia"
Actuating range
● Linear actuator
3 ... 130 mm (0.12 ... 5.12"); up to 200 mm (7.87") on request
● Part-turn actuator
30° ... 100°
Linearity (after corrections made by
positioner)
● Linear actuator
± 1 %
● Part-turn actuator
± 1 %
Hysteresis ± 0.2 %
Continuous operation temperature -40 °C to +85 °C (-40 °F to +185 °F);
extended temperature range on request
-
Vibration resistance
● Harmonics oscillation
(sine wave) to
DIN EN 60068-2-6/05.96
7 mm (0.28"), 5 to 54 Hz; 500 m/s
2
(1640 ft/s
2
), 80 to 200 Hz
Enclosure protection type IP68 according to IEC EN 60529; NEMA 4X / Encl. Type 4X
For connecting to circuits with the
following peak values
- U
i
= 5 V
C
i
= 10 nF
L
i
= 240 μH
Certificates and approvals
CE conformity The relevant directives and standards applied, including their revision levels, are
available on the Internet in our EC Declaration of Conformity.
Explosion protection Ex labels
Explosion protection in accordance
with
ATEX/IECEx FM/CSA
Intrinsic safety "ia" Zone 1:
II 2 G Ex ia IIC T6/T4 Gb
FM:
IS, Class I, Divison 1, ABCD
Class I, Zone 1, AEx ib, IIC,T6/T4
CSA:
Class I, Division 1, ABCD
Class I, Zone 1, Ex ib, IIC
Installation location
● Intrinsic safety "ia"
Zone 1
Permissible ambient temperature Zone 1
T4: -40 ... +90 °C (-40 ... +194 °F)
T6: -40 ... +70 °C (-40 ... +158 °F)
SIPART PS2 Non-Contacting Sensor (NCS)
A5E00097485-07, 01/2012
31
