8 Dimensional drawings





 


5

Figure 8-1 Dimensional drawing of the NCS
9 Scope of delivery
9.1 Scope of delivery of NCS for linear actuators
Rotary actuator 6DR4004-.N.10
Quantity Designation Notes
1 DVD Complete documentation for all variants and accessories
1 Magnet clamp
5 Washer 6
2 Hex socket head screw M6x12
1 Plastic washer
1 Magnet
1 Tensioning ring
4 Hexagon nut M6
2 Hex socket head screw M6x25
1 Non-contacting sensor Cable lengths as ordered
1 Screw F3x8
