Rotary actuator 6DR4004-.N.10
Quantity Designation Notes
1 Sealing For cable bushings
1 Plugs For closing the sealing insert
1 Cable clamp
Equipment you need in addition to the scope of delivery listed below:
● A mounting console to VDI/VDE 3845
● A SIPART PS2 positioner with built-in EMC filter module, order number 6DR5...-....2.
Or:
● An EMC filter module with order number C73451-A430-D23 for retrofitting SIPART PS2 positioners.
In order to prevent interference on the sensor, the mounting elements should be made of non-ferrous antimagnetic metal,
e.g. A4 stainless steel or aluminum.
See also
Mounting the NCS to the rotary actuator (Page 23)
9.2 Scope of delivery of NCS for linear actuators up to 14 mm (0.55 inch) .
Linear actuator with a stroke range up to 14 mm (0.55 inch) 6DR4004-.N.20
Quantity Designation Notes
1 DVD Complete documentation for all variants and accessories
for positioners
1 Magnet
5 Washer 6
2 Hex socket head screw M6x12
4 Hexagon nut M6
2 Hex socket head screw M6x25
1 Non-contacting sensor Cable lengths as ordered
1 Screw F3x8
1 Sealing For cable bushings
1 Plugs For closing the sealing insert
1 Cable clamp
Equipment you need in addition to the scope of delivery listed below:
● A SIPART PS2 positioner with built-in EMC filter module, order number 6DR5...-....2.
Or:
● An EMC filter module with order number C73451-A430-D23 for retrofitting SIPART PS2 positioners.
In order to prevent interference on the sensor, the mounting elements should be made of non-ferrous antimagnetic metal,
e.g. A4 stainless steel or aluminum.
See also
Mounting (Page 23)
