SIPART PS2 Non-Contacting Sensor (NCS)
A5E00097485
-07, 01/2012
34
9.3 Scope of delivery of NCS for linear actuators > 14 mm (0.55 inch) .
Linear actuator > 14 mm (0.55 inch) 6DR4004-.N.30
Quantity Designation Notes
1 DVD Containing the complete documentation for all device
variants
1 NCS assembly kit, completely
assembled
Mounting by means of assembly kit for NAMUR linear
drives (available on separate order; refer to the
accessories section in catalog FI 01)
With this assembly kit, the linear stroke is converted into a rotary movement by means of lever action.
In order to prevent interference on the sensor, the mounting elements should be made of non-ferrous antimagnetic metal,
e.g. A4 stainless steel or aluminum.
Equipment you need in addition to the scope of delivery listed below:
● NAMUR-Linear actuator mounting kit with short lever arm 2 to 35 mm; order number 6DR4004-8V.
● With additional extended lever arm for the range from 35 mm to 130 mm; order number 6DR4004-8L.
● A SIPART PS2 positioner with built-in EMC filter module, order number 6DR5...-....2.
Or:
● An EMC filter module with order number C73451-A430-D23 for retrofitting SIPART PS2 positioners.
See also
Mounting (Page 23)
10 Certificate
The certificates can be found on the enclosed CD and on the Internet under:
Certificates (http://www.siemens.com/processinstrumentation/certificates)
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may be trademarks whose
use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance cannot
be precluded entirely, we cannot guarantee full consistency. However, the information in this publication is reviewed regularly and any
necessary corrections are included in subsequent editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
SIPART PS2 Non-Contacting Sensor (NCS)
A5E00097485, 01/2012
