Total permissible current for contacts connected to
common potential
5 A
Switching time OOT (Output Operating Time)
Additional delay of the output medium used
Closing time, typical: 0.2 ms
Opening time, typical: 6 ms
Maximum: ≤ 9 ms
Rated data of the output contacts in accordance with
UL certification
B150
Q300
Design Data
Masses
Device Size
Weight of the Modular Devices
Type of construction 1/3 1/2 2/3 5/6 1/1
Flush-mounting device 4.8 kg 8.1 kg 11.4 kg 14.7 kg 18.0 kg
Surface-mounted device with inte-
grated on-site operation panel
7.8 kg 12.6 kg 17.4 kg 22.2 kg 27.0 kg
Surface-mounted device with
detached on-site operation panel
5.1 kg 8.7 kg 12.3 kg 15.9 kg 19.5 kg
Size Weight
Detached on-site operation panel 1/3 1.9 kg
Detached on-site operation panel 1/6 1.1 kg
Dimensions of the Basic and 1/3 Modules
Type of Construction (Maximum Dimensions)
Width over all x Height over all x Depth
11
(in
Inches)
Flush-mounting device 150 mm x 268 mm x 229 mm (5.91 x 10.55 x 9.02)
Surface-mounted device with integrated on-site oper-
ation panel
150 mm x 314 mm x 337 mm (5.91 x 12.36 x 13.27)
Surface-mounted device with detached on-site opera-
tion panel
150 mm x 314 mm x 230 mm (5.91 x 12.36 x 9.06)
Dimensions of Device Rows
Type of
Construction
(Maximum
Dimensions)
Width over all x Height over all x Depth
12
(in Inches)
Type of construc-
tion
1/3 1/2 2/3 5/6 1/1
Flush-mounting
device
150 mm x
268 mm x
229 mm (5.91 x
10.55 x 9.02)
225 mm x
268 mm x
229 mm (8.86 x
10.55 x 9.02)
300 mm x
268 mm x
229 mm(11.81 x
10.55 x 9.02)
375 mm x
268 mm x
229 mm (14.76
x 10.55 x 9.02)
450 mm x
268 mm x
229 mm (17.72
x 10.55 x 9.02)
11.1.5
11
Width and depth rounded to whole numbers in mm
12
Width and depth rounded to whole numbers in mm
Technical Data
11.1 General Device Data
560 SIPROTEC 5, Low-Impedance Busbar Protection 7SS85, Manual
C53000-G5040-C019-6, Edition 06.2016
