Page #33 background image
External Tripping Busbar Section (from Bay)
Setting Values
Supervision time 0.06 s to 1.00 s Increments of 0.01 s
Operate Time
Minimum operate time Fast relay (type F) approx. 9 ms
Tolerances
Process tolerance for the supervision time 1 % of the setting value or 10 ms
11.9
Technical Data
11.9 External Tripping Busbar Section (from Bay)
922 SIPROTEC 5, Low-Impedance Busbar Protection, Manual
C53000-G5040-C019-C, Edition 04.2021
