Trip-Circuit Supervision
Setting Values
Number of monitored circuits per circuit-breaker function group 1 to 3
Operating mode per circuit With 1 binary input
With 2 binary inputs
Pickup and dropout time Approx. 1 s to 2 s
Adjustable indication delay with 1 binary input 1.00 s to 600.00 s Increments of 0.01 s
Adjustable indication delay with 2 binary inputs 1.00 s to 30.00 s Increments of 0.01 s
11.31
Technical Data
11.31 Trip-Circuit Supervision
SIPROTEC 5, Low-Impedance Busbar Protection, Manual 983
C53000-G5040-C019-C, Edition 04.2021
