Configuration
88
7SS52 V4 Manual
C53000-G1176-C182-3
Operational indica-
tions of the clock
management
After the indication "Clock SyncError on” a time step must be expected. This in-
dication is triggered if:
• a synchronization fault has lasted for longer than the above mentioned tolerance
time or by changing the operating mode.
• a time step is anticipated afterwards; the message is displayed with the time before
the step.
The message “Clock SyncError off” is triggered if:
• the synchronization has taken effect again (e.g. after faulted reception or radio clock
reception);
• immediately after a time step; this message is displayed with the time after the step,
so that conclusions can be drawn as to the magnitude of the step.
Time format Either the European time format (DD.MM.YYYY) or the US format (MM/DD/YYYY)
can be specified for the device display.
