Protection General
175
7SS52 V4 Manual
C53000-G1176-C182-3
5.9.10 List of Information from the Central Unit
$00, .., $03 are variables which will be automatically replaced on entry in the event
buffer by
$00 Number of the bay unit
$01 Bay name
$02 Name of the switching element (e.g. isolator or circuit breaker)
$03 Name of the bus zone
5.9.11 Settings for the Bay Unit
FNo. Alarm Comments
10445 Device trip G Device Trip (group alarm)
10449 Trip BBP G Trip command BBP (group alarm)
10471 IsoProhib G Isolator oper. prohibited (group alarm)
10478 >EF charact. >Earth fault characteristic active
10486 TripRelErr Timing error trip release
10487 >TRIP-Release >TRIP-Release for external command
176.1135 $01 $02 $01 circuit breaker $02
177.1341 Trip $03 G Trip command for $03 (group alarm)
177.1360 >Trip $01 >Trip command for $03
177.1361 TripBIErr $03 Timing error ext. Trip command $03
177.1362 noTripRel $03 No release of Trip command $03
177.1363 Trip BI $03 Trip command by BI for $03
Addr. Setting Title Setting Options Default Setting Comments
128 T-BF 2chan 0.06 .. 1.00 s 0.06 s Supervision time BF start / re-
lease
1141 T TRIP 0.01..32.00 s 0.15 s Minimum trip command duration
7101 LANGUAGE integrated operator control DEUTSCH
ENGLISH
FRANCAIS
ESPANOL
ITALIANO
PYCCK.
ENGLISH
