General Device Data
325
7SS52 V4 Manual
C53000-G1176-C182-3
EMC tests for noise
emission
Standard: EN 61000-6-4 (generic standard)
– Radio disturbance voltage on lines, 150 kHz to 30 MHz
only auxiliary voltage limit value class B
IEC-CISPR 22
– Disturbance field intensity 30 MHz to 1000 MHz
IEC-CISPR 11 limit value class A
9.2.15 Mechanical Tests
Mechanical impact Standards: IEC 60255-21-1 Class II
IEC 60068-2-6 test Fc
Permissible mechanical
impact
– in service sinusoidal;
10 Hz to 60 Hz; ± 0,075 mm amplitude;
60 Hz to 150 Hz; 1 g acceleration;
frequency sweep rate 1 octave/min;
20 cycles in 3 orthogonal
axes
– during transport sinusoidal;
5Hz to 8Hz; ± 7.5 mm amplitude;
8 Hz to 150 Hz; 2 g acceleration;
frequency sweep rate 1 octave/min;
20 cycles in 3 orthogonal
axes
