Siemens SIPROTEC 7SS523 V3.3

Navigation Tree - Central Unit
403
7SS52 V4 Manual C53000-G1176-C182-3
A.18 Navigation Tree - Central Unit
The following navigation tree gives an overview of the parameter blocks and the individual parameters that can be se-
lected in the central unit of the SIPROTEC 7SS52 V4 distributed busbar and breaker failure protection. It shows the op-
erations which are necessary to achieve certain setting options.
Table A-35 Navigation tree of the central unit
1st level 2nd level 3rd level 4th level 5th level
CZ Idiff Istab
L1 xxx.x xxx.x %Ino
L2
xxxx.x yyyy.y %Ino
L3 xxx.x xxx.x %Ino
7SS5220-5FA31 1AA0
Bootsystem:V##.##.##
Firmware: V##.##.##
P-Set: V##.##.##
MAIN MENU xx/yy
>Annunciations -> x
Measurement -> x
Control -> x
Parameter -> x
Test/Diagnosis-> x
Annunciations xx/yy
>Event Log -> x
Trip Log -> x
Warnings -> x
Set/Reset -> x
EVENT LOG xx/yy
>dd.mm.yy hh:mm:ss
....................
TRIP LOG xx/yy
>Last Fault -> x
2nd Last Fault-> x
3rd Last Fault-> x
...
8th Last Fault-> x
n-TE xx/yy
>dd.mm.yy hh:mm:ss
WARNING xx/yy
>dd.mm.yy hh:mm:ss
....................
MENU
