Supervisory Functions
159
7SS52 V4 Manual
C53000-G1176-C182-3
5.5.5 List of Information from the Bay Unit
176.1127 FltR $01 $02 Fault: run time $01 isol. $02
176.1128 FltP $01 $02 Fault: dist. pos. $01 isol. $02
176.1133 FltP $01 $02 Fault: dist. pos. $01 isol. $02
176.1171 15V-superv $00 15V supply supervision $00
176.1172 5V-superv $00 5V supply supervision $00
176.1173 0V-superv $00 0V supply supervision $00
176.1174 BattSuperv $00 Battery supervision $00
176.1175 MeasInSup $00 Measured value supervision I-SUM $00
176.1190 Flt aut $00 Failure in automatic testing $00
177.1321 Id-supL1-2 $03 Id-sup $03 L1-2
177.1322 Id-supL2-2 $03 Id-sup $03 L2-2
177.1323 Id-supL3-2 $03 Id-sup $03 L3-2
177.1326 Id-supL1-3 $03 Id-sup $03 L1-3
177.1327 Id-supL2-3 $03 Id-sup $03 L2-3
177.1328 Id-supL3-3 $03 Id-sup $03 L3-3
177.1331 Id-sup $03 M Id-sup $03 M
FNo. Alarm Comments
FNo. Alarm Comments
51 Device OK Device is Operational and Protecting
143 Failure 15V Failure of internal 15 VDC power supply
145 Failure 0V Failure of internal 0 VDC power supply
161 I supervision Measured value supervision of currents
7650 Fail Com.CU Failure in communication w.Central Unit
