Siemens SIPROTEC 7SS523 V3.3

Appendix
394
7SS52 V4 Manual
C53000-G1176-C182-3
A.14 Measured Value List - Bay Unit
FNo. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type Information No. Compatibility Data Unit Position CFC Control Display Default Display
5701 IL1 = Current in phase L1 = %In
5702 IL2 = Current in phase L2 = %In
5703 IL3 = Current in phase L3 = %In
5704 IE = Earth Current = %In
5705 IL1 = Current in phase L1 = A
5706 IL2 = Current in phase L2 = A
5707 IL3 = Current in phase L3 = A
5708 IE = Earth Current = A
5709 IL1 = Current in phase IL1 = %Ino
5710 IL2 = Current in phase IL2 = %Ino
5711 IL3 = Current in phase IL3 = %Ino
5712 IE = Earth Current = %Ino
5713 IDL1 = Bus Zone: Idiff L1 = %Ino
5714 IDL2 = Bus Zone: Idiff L2 = %Ino
5715 IDL3 = Bus Zone: Idiff L3 = %Ino
5716 ISL1 = Bus Zone: Istab L1 = %Ino
5717 ISL2 = Bus Zone: Istab L2 = %Ino
5718 ISL3 = Bus Zone: Istab L3 = %Ino
5719 f [Hz] = Frequency f [Hz] = Hz
