Siemens SIPROTEC 7SS523 V3.3

Appendix 404
7SS52 V4 Manual
C53000-G1176-C182-3
Main Menu Annunciations SET/RESET xx/yy
>Event Log -> x
Trip Log -> x
Measurement xx/yy
>Operation.pri -> x
PERCENT -> x
Operation.PRI
>BU I pri -> xx
BU I PRI xx/nn
>BU01 -> xx
...
BUxx -> xx
BUxx xx/nn
>BUxx IL1= ###A
BUxx IL2= ###A
BUxx IL3= ###A
PERCENT xx/yy
>CZ Id,Is -> xx
BZ Id,Is -> xx
BU I -> xx
BU I norm -> xx
CZ ID,IS xx/yy
>CZ Id L1= ##%Ino
CZ Id L2= ##%Ino
CZ Id L3= ##%Ino
CZ Is L1= ##%Ino
CZ Is L2= ##%Ino
CZ Is L3= ##%Ino
BZ ID,IS xx/yy
>BZ01 ->xx
...
BZyy ->xx
BZyy xx/nn
>BZyy Id L1= ##%Ino
BZyy Id L2= ##%Ino
BZyy Id L3= ##%Ino
BZyy Is L1= ##%Ino
BZyy Is L2= ##%Ino
BZyy Is L3= ##%Ino
BU I xx/nn
>BU01 -> xx
...
BUxx -> xx
BUxx xx/nn
>BUxx IL1= ##%
BUxx IL2= ##%
BUxx IL = ##%
BU I xx/nn
>BU01 -> xx
...
BUxx -> xx
BUxx xx/nn
>BUxx IL1= ##%Ino
BUxx IL2= ##%Ino
BUxx IL = ##%Ino
Table A-35 Navigation tree of the central unit
1st level 2nd level 3rd level 4th level 5th level
