Siemens SIRIUS 3RV1.2 Configuration Manual

Selection tables 400 V AC
3.3 Circuit breaker + contactor + 3RB3 solid-state overload relay
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
33
Standard three-
phase motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Setting
range
Overload
release
Motor
starter
protector
Motor starter
protector
Starter
protection
3)
Contactor
2)
Overload relay
(solid-state)
Setting range
Overload
release
Overload
relay
kW A Order No. Order No. Order No.
Size
Order No. A
1,5 3,5 5,5 ... 8 3RV2011-1HA10 3RT2024-1AP00 S00/S0/S0 3RB3026-2PB0 1 ... 4
2,2 5 7 ... 10 3RV2011-1JA10 3RT2024-1AP00 S00/S0/S0 3RB3026-2SB0 3 ... 12
3 6,5 11 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0/S0 3RB3026-2QB0 6 ... 25
4 8,5 14 ... 20 3RV2021-4BA10 3RT2027-1AP00 S0/S0/S0 3RB3026-2QB0 6 ... 25
5,5 11,5 20 ... 25 3RV2021-4DA10 3RT2027-1AP00 S0/S0/S0 3RB3026-2QB0 6 ... 25
CLASS 30
0,06 0,2 0,55 ... 0,8 3RV2011-0HA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,4
0,09 0,3 0,7 ... 1 3RV2011-0JA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,4
0,12 0,4 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,32 ... 1,25
0,18 0,6 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,32 ... 1,25
0,25 0,85 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,32 ... 1,25
0,37 1,1 2,2 ... 3,2 3RV2011-1DA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4PB0 1 ... 4
0,55 1,5 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4PB0 1 ... 4
0,75 1,9 4,5 ... 6,3 3RV2011-1GA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4PB0 1 ... 4
1,1 2,7 5,5 ... 8 3RV2011-1HA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4PB0 1 ... 4
1,5 3,5 7 ... 10 3RV2011-1JA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4SB0 3 ... 12
2,2 5 11 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0/S0 3RB3123-4SB0 3 ... 12
3 6,5 14 ... 20 3RV2021-4BA10 3RT2027-1AP00 S0/S0/S0 3RB3123-4QB0 6 ... 25
4 8,5 20 ... 25 3RV2021-4DA10 3RT2027-1AP00 S0/S0/S0 3RB3123-4QB0 6 ... 25
5,5 11,5 27 ... 32 3RV2021-4EA10 3RT2027-1AP00 S0/S0/S0 3RB3123-4QB0 6 ... 25
Order numbers for basic versions with screw terminals and spring-loaded terminals also possible. 3RA2921-1BA00 link
module can only be used with screw terminals.
1)
Guide value for 4-pole standard motors at 400 V AC, 50 Hz. Selection depends on the concrete startup and rated data
of the protected motor.
2)
Rated control supply voltage 230 V AC, 50 Hz, other control voltages possible.
3)
The motor starter protector is to be set to maximum current value.
