Siemens SIRIUS 3RV1.2 Configuration Manual

Selection tables 500 V AC
4.2 Motor starter protector + contactor + thermal overload relay
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
55
4.2 Motor starter protector + contactor + thermal overload relay
CLASS 10, type of coordination 1,
short-circuit breaking capacity
I
q
= 100 kA
$
&9
Standard three-phase
motor 4-pole at
400 V AC
1)
Standard
output P
Motor
current I
Motor starter
protector Starter
protection
Contactor
2)
Thermal overload
relay
Setting range
Overload
release
Overload relay
kW A Order No. Order No.
Size
Order No. A
0,04 0,11 3RV2311-0AC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0AB0 0,11 ... 0,16
0,06 0,16 3RV2311-0BC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0BB0 0,14 ... 0,20
0,09 0,24 3RV2311-0CC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0CB0 0,18 ... 0,25
0,09 0,24 3RV2311-0DC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0DB0 0,22 ... 0,32
0,12 0,32 3RV2311-0EC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0EB0 0,28 ... 0,40
0,18 0,48 3RV2311-0FC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0FB0 0,35 ... 0,50
0,18 0,48 3RV2311-0GC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0GB0 0,45 ... 0,63
0,25 0,68 3RV2311-0HC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0HB0 0,55 ... 0,80
0,37 0,88 3RV2311-0JC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0JB0 0,70 ... 1,00
0,55 1,2 3RV2311-0KC10 3RT2015-1AP01 S00/S00/S00 3RU2116-0KB0 0,90 ... 1,25
0,55 1,2 3RV2311-1AC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1AB0 1,1 ... 1,6
0,75 1,5 3RV2311-1AC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1AB0 1,1 ... 1,6
0,75 1,5 3RV2311-1BC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1BB0 1,4 ... 2,0
1,1 2,2 3RV2311-1CC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1CB0 1,8 ... 2,5
1,5 2,9 3RV2311-1DC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1DB0 2,2 ... 3,2
2,2 3,9 3RV2311-1EC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1EB0 2,8 ... 4,0
2,2 3,9 3RV2311-1FC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1FB0 3,5 ... 5,0
3 5,2 3RV2311-1GC10 3RT2015-1AP01 S00/S00/S00 3RU2116-1GB0 4,5 ... 6,3
4 6,8 3RV2311-1HC10 3RT2016-1AP06 S00/S00/S00 3RU2116-1HB0 5,5 ... 8,0
5,5 9,2 3RV2311-1JC10 3RT2017-1AP01 S00/S00/S00 3RU2116-1JB0 7,0 ... 10,0
7,5 12,4 3RV2311-1KC10 3RT2018-1AP01 S00/S00/S00 3RU2116-1KB0 9,0 ... 12,5
7,5 12,4 3RV2311-4AC10 3RT2018-1AP01 S00/S00/S00 3RU2116-4AB0 11 ... 16
11 17,6 3RV2321-4BC10 3RT2026-1AP00 S0/S0/S0 3RU2126-4BB0 14 ... 20
11 17,6 3RV2321-4CC10 3RT2026-1AP00 S0/S0/S0 3RU2126-4CB0 17 ... 22
15 23 3RV2321-4DC10 3RT2027-1AP00 S0/S0/S0 3RU2126-4DB0 20 ... 25
