Siemens SIRIUS 3RV1.2 Configuration Manual

Selection tables 500 V AC
4.4 Motor starter protector + contactor + 3RB22, 3RB23 solid-state overload relay, or 3UF7
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
63
4.4 Motor starter protector + contactor + 3RB22, 3RB23 solid-state
overload relay, or 3UF7
Type of coordination 2,
short-circuit breaking capacity
I
q
= 100 kA
$
&9
Standard
three-phase
motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Motor starter
protector
Starter
protection
3)
Contactor
2)
Overload relay (solid-
state)
Setting range
Overload
release
Overload relay
kW A
Setting
range
Overload
release
Motor
starter
protector
Order No. Order No.
Size
Order No. A
CLASS 10
0,12 0,32 0,4 3RV2311-0EC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,18 0,48 0,63 3RV2311-0GC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,25 0,68 0,8 3RV2311-0HC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,37 0,88 1 3RV2311-0JC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,55 1,20 1,25 3RV2311-0KC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,75 1,50 1,6 3RV2311-1AC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
1,1 2,20 2,5 3RV2311-1CC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
1,5 2,90 3,2 3RV2311-1DC10 3RT2015-1AP01 S00/S00 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
2,2 3,90 5 3RV2311-1FC10 3RT2024-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
2,2 3,90 5 3RV2311-1FC10 3RT2024-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
3 5,20 8 3RV2311-1HC10 3RT2026-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
4 6,80 8 3RV2311-1HC10 3RT2026-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
