Selection tables 500 V AC
4.4 Motor starter protector + contactor + 3RB22, 3RB23 solid-state overload relay, or 3UF7
Configuring SIRIUS Innovations
64 Configuration Manual, 04/2010, A8E56203880102-02
Standard
three-phase
motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Motor starter
protector
Starter
protection
3)
Contactor
2)
Overload relay (solid-
state)
Setting range
Overload
release
Overload relay
kW A
Setting
range
Overload
release
Motor
starter
protector
Order No. Order No.
Size
Order No. A
7,5 12,40 20 3RV2321-4BC10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
10,0 ... 100,00
5,5 9,20 10 3RV2311-1JC10 3RT2026-1AP00 S00/S0 3UF7102-1AA00-0/
3RB2906-2JG1
2,4 ... 25,00
11 17,60 22 3RV2321-4CC10 3RT2027-1AP00 S0/S0 3UF7102-1AA00-0/
3RB2906-2JG1
10,0 ... 100,00
15 23,00 32 3RV2321-4EC10 3RT2027-1AP00 S0/S0 3UF7102-1AA00-0/
3RB2906-2JG1
10,0 ... 100,00
Short-circuit breaking capacity I
q
= 36 kA
18,5 28,00 36 3RV2321-4PC10 3RT1035-1AP00 S0/S2 3UF7102-1AA00-0/
3RB2906-2JG1
10,0 ... 100,00
CLASS 20
0,12 0,32 0,6 ... 0,8 3RV2011-0HA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,18 0,48 0,9 ... 1,25 3RV2011-0KA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,25 0,68 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,37 0,88 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,55 1,20 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,75 1,50 2,2 ... 3,2 3RV2011-1DA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
1,1 2,20 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
1,5 2,90 4,5 ... 6,3 3RV2011-1GA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
2,2 3,90 7,0 ... 10 3RV2011-1JA10 3RT2026-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
2,2 3,90 10 3RV2311-1JC10 3RT2026-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
3 5,20 11,0 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
4 6,80 14,0 ... 20 3RV2021-4BA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
5,5 9,20 27,0 ... 32 3RV2021-4EA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
7,5 12,40 27,0 ... 32 3RV2021-4EA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
