Siemens SIRIUS 3RV1.2 Configuration Manual

Selection tables 500 V AC
4.4 Motor starter protector + contactor + 3RB22, 3RB23 solid-state overload relay, or 3UF7
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
65
Standard
three-phase
motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Motor starter
protector
Starter
protection
3)
Contactor
2)
Overload relay (solid-
state)
Setting range
Overload
release
Overload relay
kW A
Setting
range
Overload
release
Motor
starter
protector
Order No. Order No.
Size
Order No. A
Short-circuit breaking capacity I
q
= 36 kA
11 17,60 30,0 ... 36 3RV2021-4PA10 3RT1035-1AP00 S0/S2 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
CLASS 30
0,12 0,32 0,9 ... 1,25 3RV2011-0KA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,18 0,48 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,25 0,68 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,37 0,88 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,55 1,20 2,8 ... 4 3RV2011-1EA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
0,75 1,50 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
1,1 2,20 4,5 ... 6,3 3RV2011-1GA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
1,5 2,90 7,0 ... 10 3RV2011-1JA10 3RT2026-1AP00 S00/S0 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3,00
2,2 3,90 9,0 ... 12,5 3RV2011-1KA10 3RT2026-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
3 5,20 11,0 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
4 6,80 14,0 ... 20 3RV2021-4BA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
5,5 9,20 20,0 ... 25 3RV2021-4DA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
7,5 12,40 27,0 ... 32 3RV2021-4EA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
Short-circuit breaking capacity I
q
= 36 kA
7,5 12,40 30,0 ... 36 3RV2021-4PA10 3RT1035-1AP00 S0/S2 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25,00
Order numbers for basic versions with screw terminals and spring-loaded terminals also possible. 3RA2921-1BA00 link
module can only be used with screw terminals.
1)
Guide value for 4-pole standard motors at 500 V AC, 50 Hz. Selection depends on the concrete startup and rated data
of the protected motor.
2)
Rated control supply voltage 230 V AC, 50 Hz, other control voltages possible.
3)
The motor starter protector is to be set to maximum current value.
