Siemens SIRIUS 3RV1.2 Configuration Manual

Selection tables 500 V AC
4.3 Motor starter protector + contactor + 3RB3 solid-state overload relay
Configuring SIRIUS Innovations
62 Configuration Manual, 04/2010, A8E56203880102-02
Standard three-
phase motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Motor starter
protector
Starter protection
3)
Contactor
2)
Overload relay
(solid-state)
Setting range
Overload
release
Overload
relay
kW A
Setting
range
Overload
release
Motor
starter
protector
Order No. Order No.
Size
Order No. A
0,37 0,88 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2NB0 0,3 ... 1,25
0,55 1,20 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2PB0 1,0 ... 4,00
0,75 1,50 2,2 ... 3,2 3RV2011-1DA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2PB0 1,0 ... 4,00
1,1 2,20 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0/S0 3RB3026-2PB0 1,0 ... 4,00
1,5 2,90 4,5 ... 6,3 3RV2011-1GA10 3RT2024-1AP00 S00/S0/S0 3RB3026-2PB0 1,0 ... 4,00
2,2 3,90 7,0 ... 10 3RV2011-1JA10 3RT2026-1AP00 S00/S0/S0 3RB3026-2SB0 3,0 ... 12,00
2,2 3,90 7,0 ... 10 3RV2011-1JA10 3RT2026-1AP00 S00/S0/S0 3RB3026-2SB0 3,0 ... 12,00
3 5,20 11,0 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0/S0 3RB3026-2SB0 3,0 ... 12,00
4 6,80 14,0 ... 20 3RV2021-4BA10 3RT2027-1AP00 S0/S0/S0 3RB3026-2QB0 6,0 ... 25,00
5,5 9,20 20,0 ... 25 3RV2021-4DA10 3RT2027-1AP00 S0/S0/S0 3RB3026-2QB0 6,0 ... 25,00
7,5 12,40 27,0 ... 32 3RV2021-4EA10 3RT2027-1AP00 S0/S0/S0 3RB3026-2QB0 6,0 ... 25,00
CLASS 30
0,04 0,11 0,32 3RV2311-0DC10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,40
0,06 0,16 0,4 ... 0,5 3RV2011-0FA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,40
0,09 0,24 0,6 ... 0,8 3RV2011-0HA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,40
0,12 0,32 0,9 ... 1,25 3RV2011-0KA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,18 0,48 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,25 0,68 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,37 0,88 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,55 1,20 2,8 ... 4 3RV2011-1EA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4PB0 1,0 ... 4,00
0,75 1,50 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4PB0 1,0 ... 4,00
1,1 2,20 4,5 ... 6,3 3RV2011-1GA10 3RT2024-1AP00 S00/S0/S0 3RB3123-4PB0 1,0 ... 4,00
1,5 2,90 7,0 ... 10 3RV2011-1JA10 3RT2026-1AP00 S00/S0/S0 3RB3123-4PB0 1,0 ... 4,00
2,2 3,90 9,0 ... 12,5 3RV2011-1KA10 3RT2026-1AP00 S00/S0/S0 3RB3123-4SB0 3,0 ... 12,00
Order numbers for basic versions with screw terminals and spring-loaded terminals also possible. 3RA2921-1BA00 link
module can only be used with screw terminals.
1)
Guide value for 4-pole standard motors at 500 V AC, 50 Hz. Selection depends on the concrete startup and rated data
of the protected motor.
2)
Rated control supply voltage 230 V AC, 50 Hz, other control voltages possible.
3)
The motor starter protector is to be set to maximum current value.
