Selection tables 400 V AC
3.4 Circuit breaker + contactor + 3RB22 or 3RB23 solid-state overload relay, and 3UF7
Configuring SIRIUS Innovations
36 Configuration Manual, 04/2010, A8E56203880102-02
Type of coordination 2,
short-circuit breaking capacity
I
q
= 150 kA
&9
Standard three-
phase motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Setting
range
Overload
release
Motor
starter
protector
Motor starter
protector
Starter protection
3)
Contactor
2)
Overload relay (solid-
state)
or current measuring
module
4)
Setting
range
Overload
release
Overload
relay
kW A Order No. Order No. Order No.
Size
Order No. A
CLASS 10
0,09 0,3 None 3RV2311-0DC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
0,12 0,4 None 3RV2311-0FC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
0,18 0,6 None 3RV2311-0HC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
0,25 0,85 None 3RV2311-0JC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
0,37 1,1 None 3RV2311-0KC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
0,55 1,5 None 3RV2311-1AC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
0,75 1,9 None 3RV2311-1BC10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0/
3RB2906-2BG1
0,3 ... 3
1,1 2,7 None 3RV2311-1DC10 3RT2015-1AP01 S00/S00 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
1,5 3,5 None 3RV2311-1EC10 3RT2015-1AP01 S00/S00 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
2,2 5 None 3RV2311-1GC10 3RT2024-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
3 6,5 None 3RV2311-1HC10 3RT2024-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
4 8,5 None 3RV2311-1JC10 3RT2024-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
5,5 11,5 None 3RV2311-4AC10 3RT2026-1AP00 S00/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
7,5 15,5 None 3RV2321-4CC10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
11 22 None 3RV2321-4EC10 3RT2027-1AP00 S0/S0 3UF7102-1AA00-0/
3RB2906-2JG1
10 ... 100
