Siemens SIRIUS 3RV1.2 Configuration Manual

Selection tables 400 V AC
3.4 Circuit breaker + contactor + 3RB22 or 3RB23 solid-state overload relay, and 3UF7
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
39
Standard three-
phase motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Setting
range
Overload
release
Motor
starter
protector
Motor starter
protector
Starter protection
3)
Contactor
2)
Overload relay (solid-
state)
or current measuring
module
4)
Setting
range
Overload
release
Overload
relay
kW A Order No. Order No. Order No.
Size
Order No. A
CLASS 40
0,09 0,3 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0 0,3 ... 3
0,12 0,4 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0 0,3 ... 3
0,18 0,6 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0 0,3 ... 3
0,25 0,85 2,2 ... 3,2 3RV2011-1DA10 3RT2015-1AP01 S00/S00 3UF7100-1AA00-0 0,3 ... 3
0,37 1,1 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0 0,3 ... 3
0,55 1,5 3,5 ... 5 3RV2011-1FA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0 0,3 ... 3
0,75 1,9 4,5 ... 6,3 3RV2011-1GA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0 0,3 ... 3
1,1 2,7 7 ... 10 3RV2011-1JA10 3RT2024-1AP00 S00/S0 3UF7100-1AA00-0 0,3 ... 3
1,1 2,7 7 ... 10 3RV2011-1JA10 3RT2024-1AP00 S00/S0 3UF7101-1AA00-0 2,4 ... 25
1,5 3,5 11 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0 3UF7101-1AA00-0 2,4 ... 25
2,2 5 11 ... 16 3RV2021-4AA10 3RT2026-1AP00 S0/S0 3UF7101-1AA00-0 2,4 ... 25
3 6,5 20 ... 25 3RV2021-4DA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0 2,4 ... 25
4 8,5 27 ... 32 3RV2021-4EA10 3RT2027-1AP00 S0/S0 3UF7101-1AA00-0 2,4 ... 25
Order numbers for basic versions with screw terminals and spring-loaded terminals also possible. 3RA2921-1BA00 link
module can only be used with screw terminals.
1)
Guide value for 4-pole standard motors at 400 V AC, 50 Hz. Selection depends on the concrete startup and rated data
of the protected motor.
2)
Rated control supply voltage 230 V AC, 50 Hz, other control voltages possible.
3)
The motor starter protector is to be set to maximum current value.
4)
The necessary current measuring modules are specified. The corresponding basic units 3RB22 / 3RB23 and 3UF7 are
additionally required.
