Siemens SIRIUS 3RV1.2 Configuration Manual

Fused selection tables up to 690 V
5.4 Short-circuit protection: Contactor + 3UF7 + 3RB22 / 23 solid-state overload relay
Configuring SIRIUS Innovations
80 Configuration Manual, 04/2010, A8E56203880102-02
Table 5- 9 Derating values CLASS 40
CLASS
40 (3UF7 only)
Overload relay Overload relay
Setting range
Contactor
AC-3 derating values
MLFB A MLFB kW 400 V 500 V 690 V
Size S00
Stand-alone assembly 3,0 3,0 3,0
3RT2015 3,0 3,0 3,0 3,0
3RT2016 4,0 3,0 3,0 3,0
3RT2017 5,5 3,0 3,0 3,0
3UF7100-1AA00-
0
0,3 ... 3,0
3RT2018 7,5 3,0 3,0 3,0
3RT2015 3,0 7,0 6,0 4,9
3RT2016 4,0 8,0 7,7 6,7
3RT2017 5,5 8,0 8,0 6,7
3UF7101-1AA00-
0
2,4 ... 25
3RT2018 7,5 8,3 8,3 8,3
Size S0
Stand-alone assembly 25 25 25
3RT2024 5,5 12,0 12,0 9,0
3RT2025 7,5 13,0 13,0 13,0
3RT2026 11,0 13,0 13,0 13,0
3RT2027 15,0 15,0 15,0 15,0
3UF7101-1AA00-
0
2,4 ... 25
3RT2028 18,5 15,0 15,0 15,0
Stand-alone assembly 100 100 100
3RT2024 5,5 12,0 12,0 —
3RT2025 7,5 13,0 13,0 13,0
3RT2026 11,0 13,0 13,0 13,0
3RT2027 15,0 15,0 15,0 15,0
3UF7102-1AA00-
0
10 ... 100
3RT2028 18,5 15,0 15,0 15,0
