Installation guidelines
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
93
Combination
Output
Distance between feeders
Permissible installation: h = horizontal, v = vertical
Max. ambient temperature
Vibration and shock
1
Motor starter protector and
contactor
A mm h, v °C
3RA22 reversing starter, spring-loaded terminal, busbar
0 h 60 ≤ 14
0 v 40
10 h 60
S00
14 … 16
10 v 40
Vibration and shock kit 8US1998-1CA10 required
0 h 60 ≤ 29
0 v 40
10 h 60
S0
29 … 32
10 v 40
Vibration and shock kit 8US1998-1CA10 required
Motor starter protector and soft starter, screw terminal, DIN rail or wall
S00 16
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
S0 32
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
Motor starter protector and soft starter, spring-loaded terminal, DIN rail or wall
S00 16
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
S0 32
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
Motor starter protector and solid-state contactor, screw terminal, DIN rail or wall
Direct starter
2) 2)
Unlimited Not approved for railways, power plants, or
shipbuilding.
Reversing starter
2) 2)
Unlimited Not approved for railways, power plants, or
shipbuilding.
1)
Vibration and shock tests are carried out in accordance with SN 31205 as well as with the relevant standards for
railways, shipbuilding, and power plants.
2)
Please consult Technical Assistance (www.siemens.com/industrial-controls/technical-assistance).
