Siemens SIRIUS 3RW40 2 User Manual

3ZX1012-0RW40-2DA1 7
English
Display overview
LED displays on 3RW40 Auxiliary contacts
Soft starter Motor protection
3RW40
DEVICE
(rd/gn/ylw)
STATE /
BYPASSED
/ FAILURE
(gn/rd)
OVERLOAD
(rd)
RESET
MODE
(ylw/gn)
13 14
(ON)
13 14
(RUN)
24 23
(BYPASSED)
96 95 98
FAILURE /
OVERLOAD
U
s
= 0
Operating state
IN
OFF
0
Start-up
1
Bypassed
1
Run-out
0
Warning
Ie / class setting invalid
Start-up locked, device too warm
Error
Supply voltage electronics invalid
Invalid Ie / class setting and IN (0 -> 1)
Motor protection switch-off
Overload relay / thermistor
Thermistor motor protection
Wire break / short circuit
Thermal overload device
- Missing load voltage
- Phase failure, no load
Device fault
Test function
1)
Press TEST for t > 5 s
RESET MODE (press to change)
Manual Reset
Auto Reset
Remote Reset see Fig. 6.2
LED display
1)
Motor protection shutdown test
gn
=
ylw
=
rd
=
OFF ON flashing flickering green yellow red
WARNING
Automatic restart.
May result in death, serious injury or damage to property.
The automatic reset mode (RESET MODE) must not be used in applications where an unexpected restart of the motor after the
recovery time has elapsed may lead to personal injury or damage to property.
The start command (e.g. by the PLC) must be reset before a reset command, since an automatic restart is executed when a start
command is pending after the reset command. This especially applies to motor protection tripping. For safety reasons we recommend
you integrate the group fault output (terminals 95 and 96) into the control.
gn
gn
gn
gn gn
gn
gn
gn
gn
gn
ylw
rd
gn rd
gn
gn
ylw rd
gn rd
rd rd
gn rd
ylw
gn
!

Siemens SIRIUS 3RW40 2 Specifications

General

Type	Soft Starter
Rated Operational Voltage	200-480 V AC
Protection Class	IP20
Operating Temperature	-25...60 °C
Mounting Type	DIN Rail
Number of Auxiliary Contacts	2 NO
Control Voltage	24 V AC/DC or 110-230 V AC
