3.10 OPC UA server
SITOP UPS1600 / BAT1600 / UPS1100
172 Equipment Manual, 07.2021, A5E37775406-11-76
Display name
Data type
Definition
Description
HardwareBuffering
EnableClamp
Boolean
PropertyType
Enable buffering
HardwareEnable
ResetClamp
Boolean
PropertyType
When input voltage returns during buffering, the output is
switched off for a configurable time in order to reset con-
nected devices.
HardwareStartFrom
BatteryClamp
Boolean
PropertyType
Setting for 'Start from battery' on signal terminal
3.10.6.13 Identification
Display name
Data type
Definition
Description
IdentificationContact
Setpoint
String[64]
PropertyType
Contact
IdentificationDevice
NameSetpoint
String[32]
PropertyType
PROFINET device name
IdentificationLocation
Setpoint
String[44]
PropertyType
Location ID
Note
The various S7 systems interpret parameter "IdentificationLocationSetpoint" differently.
S7
-1200 and S7-1500 correctly process the data sets.
S7
-300, S7-400 and ET200SP do not fully support this data. Proceed as follows to correctly
save this data to these PLCs:
•
Write the data to identify the devices in the PLC code using function "WR_REC".
•
Read the data to identify the devices using the "RD_REC" functions.
For the ET200SP, a description of the two functions can be found here:
(https://support.industry.siemens.com/cs/de/en/view/58649293
)
•
Alternatively, use the PRONETA
(
https://support.industry.siemens.com/cs/ww/de/view/67460624) tool to read and write
data
3.10.6.14 Lock
Display name
Data type
Definition
Description
BreakLock
1)
Method
Method
ExitLock
Method
Method
Lock for write access is withdrawn
InitLock
Method
Method
Locks write access for other users
Locked
Boolean
PropertyType
Locked
LockingClient
String[16]
PropertyType
IP address of the blocking user
LockingUser
String
PropertyType
User that had locked
