SITRANS P, DS III series (7MF4.33.. 7MF4.34.. 7MF4.35..)
4 A5E03434631-02, 12/2012
1.2 History
This history establishes the correlation between the current documentation and the valid firmware of the device.
The documentation of this edition is applicable for the following firmware:
Edition Firmware identifier nameplate System integration Installation path for PDM
12/2012 HART:
FW: 11.03.03, FW: 11.03.04,
FW: 11.03.05, FW: 11.03.06
PA/FF: FW: 0300.01.08
PDM 6.0; Dev. Rev.3
DD Rev.2
SITRANS P DSIII.2
1.3 Purpose
Overview
Depending on the version, a transmitter measures corrosive, non-corrosive and hazardous gases, vapors and liquids.
You can use the transmitter for the following types of measurement:
● Gauge pressure
● Absolute pressure
● Differential pressure
With appropriate parameter settings and the necessary add-on parts (e.g. flow orifices and remote seals), the pressure
transmitter can also be used for the following measurements:
● Level
● Volume
● Mass
● Volume of flow
● Mass flow rate
The output signal is always a load-independent direct current between 4 and 20 mA.
You can install the "intrinsically-safe" or "explosion-proof" version of the transmitter in hazardous areas. The devices have an
EC type examination certificate and comply with the appropriate harmonized European CENELEC directives.
Transmitters with remote seals of different shapes can be delivered for special applications. For example, measuring high-
viscosity substances is a special application.
Operate the device in accordance with the specifications in Section Technical specifications (Page 36).
F
or additional information, please refer to the operating instructions for the device.
