PSA / PVA Installation Guide
April 20, 2023 Sifos Technologies Page 8
with test port 1 on the left and test port 2 on the right.
See the PVA-3000 Technical Reference Manual for further information concerning the internal architecture and the
LED indicator features of each PhyView Analyzer test port.
2.3. Physical and Environmental Specifications
PHYSICAL
PSA-3002, PVA-3002, PDA-LLDP
Width: 4.2”
Height: 1.65”
Depth: 9.15” (Including Rear-Panel Connectors)
Weight: 1.4 lbs.
Power: 5V, 1.2A Max. (100VAC – 240VAC, 50-60Hz Wall Plug-in Adaptor Supplied)
PSA-3000, PSL-3000, PSA-3x48, PSL-3x24
Width: 19”
Height: 5.25” (3 Rack-Unit)
Depth: 12”
Weight per Chassis: 20.4 lbs. (PSA-3000, PSL-3000, PSA-3x48, PSL-322412 Slots Fully Populated)
Weight per Chassis: 24.8 lbs. (PSL-3424)
Power: 100VAC-240VAC, 50-60Hz, 1.35A Max.
Mains supply voltage fluctuations are not to exceed +/- 10% of the nominal
supply voltage
PSA-3402
Width: 7.5”
Height: 3.0”
Depth: 10.0”
Weight: 3.2 lbs.
Power: 100VAC – 240VAC, 50-60 Hz, 0.25A Max.
ENVIRONMENTAL
Operating Temperature: 5°C to 40°C
Storage Temperature: -20°C to 85°C
Operating Humidity: 5% to 95% RH, Non-Condensing
Altitude: 2000 Meters
Pollution Degree: 2
2.4. Certifications
Emissions: FCC Part 15, Class A
Meets EN55011, VCCI, AS/NZS 3548, ICES-001
Safety: CSA Listed (CSA22.2 No. 61010)
Meets EN61010-1 (All except PSA-3402)
Meets EN61010-12 (PSA-3402)
European Commission: Low Voltage Directive (2014/35/EU)
Electromagnetic Compatibility Directive (2014/30/EU)
CE Marking Directive (93/68/EEC)
FCC Statement:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case users will be required to correct the
interference at their own expense.
