Appendix 1 : Sigineer Power 1500W
Inverter/Charger Spec Sheet
Electrical Specifications
Model #
PSW71512NC
PSW71524NC
Inverter Output
Continuous Output Power
1500W
1500W
Surge Rating(20s)
4500W
4500W
Output Waveform
Pure Sine wave/Same as input(Bypass mode)
Nominal Efficiency
90%(Peak)
Line Mode Efficiency
>95%
Power Factor
0.9-1.0
Nominal Output Voltage RMS
120Vac
Output Voltage Regulation
±5% RMS
Output Frequency
50/60Hz ± 0.3Hz
Short Circuit Protection
Yes, Current Limit Function (Fault after 1sec)
Typical transfer Time
10ms(Max)
THD
Pure Sine, less than 5% THD Typical
DC Input
Nominal Input Voltage
12Vdc
24Vdc
Minimum Start Voltage
0Vdc
0Vdc
Low Battery Alarm
10.5/11.0/12/12.5Vdc
21/22/24/25Vdc
Low Battery Trip
10/10.5/11.5/12 Vdc
20/21/23/24Vdc
High Voltage Alarm & Fault
16.0Vdc
32Vdc
High DC Input Recovery
15.5Vdc
31Vdc
Low Battery Voltage Recover
13.0Vdc
26Vdc
Idle Consumption-Search Mode
< 25 W when Power Saver On
AC Charge
Input Voltage Range
Narrow: 100~135VAC/ 194-243Vac
Wide: 90~135VAC / 164V-263Vac
Input Frequency Range
Narrow: 47-55±0.3Hz for 50Hz, 57-65±0.3Hz for 60Hz
Wide:43±0.3Hz plus for 50Hz/60Hz
Output Voltage
Depends on battery type
Charger Breaker
Rating(120Vac)
10A
10A
Max Charge Rate
55A
25A
Over Charge Protection
Shutdown
15.7V for 12Vdc, 31.4V for 24Vdc
Charge Voltage for 12V Models
Boost Charge(C.V)
Float Charge
Gel U.S.A
1
13.7
A.G.M 1
14.1
13.4
Lithium Ion (LiFeP04)
14.6
13.7
Sealed Lead Acid
14.4
13.6
Gel Euro
14.4
13.8
Open Lead Acid
14.8
13.3
Calcium
15.1
13.6
