Sigineer Power PSW71512NC User Manual

www.sigineer.com
34
Appendix 2 : Sigineer Power 2000W-6000W
Inverter/Charger Spec Sheet
Electrical Specifications
Model
2KW
3KW
4KW
5KW
6KW
Inverter Output
Continuous Output Power
2000W
3000W
4000W
5000W
6000W
Surge Rating(20s)
6000W
9000W
12000W
15000W
18000W
Capable of Starting Electric Motor
2HP
3HP
4HP
5HP
6HP
Output Waveform
Pure Sine wave/Same as input(Bypass mode)
Peak Efficiency
88%
Line Mode Efficiency
>95%
Power Factor
0.9-1.0
Nominal Output Voltage rms
100-110-120Vac / 220-230-240Vac
Output Voltage Regulation
±10% RMS
Output Frequency
50/60Hz ± 0.3Hz
Short Circuit Protection
Yes, Current Limit Function (Fault after 1sec)
Typical transfer Time
10ms(Max)
THD
< 10%
DC Input
Nominal Input Voltage
12.0Vdc
( *2 for 24Vdc, *4 for 48Vdc)
Minimum Start Voltage
10.0Vdc
Low Battery Alarm
10.5Vdc / 11.0Vdc
Low Battery Trip
10.0Vdc / 10.5Vdc
High Voltage Alarm & Fault
16.0Vdc
High DC Input Recovery
15.5Vdc
Low Battery voltage recover
13.0Vdc
Sleep Mode Threshold
> 25 W when Power Saver On
Charge
Input Voltage Range
Narrow: 100~135VAC / 194~243VAC;
Wide: 90~135VAC / 164~260VAC;
Input Frequency Range
Narrow: 47-55±0.3Hz for 50Hz, 57-65±0.3Hz for 60Hz
Wide:43±0.3Hz plus for 50Hz/60Hz
Output Voltage
Depends on battery type
Charger Breaker Rating(230Vac)
10A
20A
20A
30A
30A
Charger Breaker Rating(120Vac)
20A
30A
40A
N/A
N/A
Max Charge Rate
See specific charge rates in “AC Charger” section
Over Charge Protection Shutdown
15.7V for 12Vdc ( *2 for 24Vdc, *4 for 48Vdc)
Battery type
Fast Charge/ Float Charge
Gel U.S.A
14/13.7
A.G.M 1
14.1/13.4
A.G.M 2
14.6/13.7
Sealed Lead Acid
14.4/13.6
Gel Euro
14.413.8
