2.4 Features
Auto Generator Start
Battery Temperature Sensing for increased charging precision
Lithium Battery(0Vdc) Wakeup
Automatic Neutral to Ground Bonding for 120Vac models
Maximum THD: 3% at nominal battery voltage
Maximum 90% conversion efficiency
Powerful 4-stage power factor corrected battery charger, settable from 0%-100%
High surge output capability, 300% peak load for 20 seconds
Fully isolated AC output from battery input
Ultra low quiescent current, low power ‘Power Saver Mode’ to conserve energy
Battery type selector for 8 types of batteries and de-sulphation for completely drained batteries
10 ms transfer time from AC to battery for the continuous load operation
Optional remote control with LCD display
15 sec DC to AC transfer delay, improved protection for generator driven loads
Thermally controlled variable speed fan for more efficient cooling
Extensive protections against various harsh situations
